19.4.2 Volume Flow and Pressure
The parameterization of the factors Nominal Volumetric Flow 397 and Nominal
Pressure 398 is necessary if the matching actual values Volumetric Flow 285
and
Pressure 286 are used to monitor the drive. The conversion is done using the elec-
trical control parameters.
Volume flow 285 and Pressure 286
are referred to the
Effective current 214
in the case of the sensorless control methods. In the case of
the field-oriented control methods, they are referred to the torque-
forming current
component
Isq
216.
Volume Flow and Pressure
No.
Description
Function
285 Volumetric flow Calculated volume flow with the unit m
3
/h.
286 Pressure
Pressure calculated according to the character-
istic with the unit kPa.
06/13 Operating Instructions ACU 263
