Bonnet OPTIMUM 700 - Default Chapter; Table of Contents

Page 1 3BE390580NI – 07/07
BONNET CIDELCEM GRANDE CUISINE
Siége social:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
TABLE OF CONTENTS
ELECTRIC
TOPS AND UNITS
A) TECHNICAL CHARACTERISTICS........................................................... 2
B) TECHNICAL INSTRUCTIONS FOR THE INSTALLER
1. FIRM PLATES ………………........................................…........................................................ 51
1.1 PLATE …………..……….……...….……...…...………..................................................................... 51
1.2 LOCATION OF THE PLATE ……...………….....……………………………………………………. 51
2. INSTALLATION: GENERALITIES ……….…….………………………………...………………… 52
2.1 GENERAL REQUIREMENTS ………..……….……...….……...…...……........................................ 52
2.2 HANDLING ………….….....…………………………………………..……………………………….. 52
2.3 UNPACKING ………...…………..………………………..……………............................................... 52
2.4 ACCESS TO THE COMPONENTS LOCATED BEHIND THE FASCIA ........................................ 53
3. INSTALLATION: PUTTING IN PLACE .……………………………………….….….……………. 54
3.1 READY-TO-INSTALL TOP ………….............................................................................................. 55
3.2 COOKING UNITS …………………………………………………..………….................................. 58
4. INSTALLATION: CONNECTIONS ……………………………………………...….………………. 66
4.1 ELECTRIC CONNECTION ………..……………..…...……...………..…….……………………….. 66
4.2 WATER CONNECTION .…….…...……...……………………………..…......................................... 68
4.3 DRAINAGE CONNECTION ….……….……………………………………........................................ 69
