Bonnet OPTIMUM 700 - A) Technical Characteristics

Page 2 3BE390580NI – 07/07
BONNET CIDELCEM GRANDE CUISINE
Siége social:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
A: TECHNICAL CHARACTERISTICS
OPTIMUM 700, Electric cooking top, round plates
P075475 P075476
MODEL
B-D706.PE400 B-D706.PE800
DIMENSIONS (mm)
Height 297 297
Width 400 800
Depth 730 730
Plate diameter 220 220
PACKAGING (mm)
Height 490 490
Width 500 900
Depth 830 830
WEIGHT (KG)
COMPOSITION OF THE TOP
Round plates 2.6 kW 2 4
ELECTRICITY (Three-phase 230V+T or 400V+N+T)
Power (kW) 230V 3a.c. 5.2 10.4
400V 3Na.c. 5.2 10.4
Max. intensity (A) 230V 3a.c. 19.6 30
400V 3Na.c. 11.3 17.2
ELECTRIC CONNECTION
Electric outlet at 615 mm above the floor.
This document is not contractual; Edition 05/2007 – 3BE0373FT
ELECTRIC connection
(Foresee a cable with 1.5 m free end)
