Bonnet OPTIMUM 700 - Page 4

Page 3 3BE390580NI – 07/07
BONNET CIDELCEM GRANDE CUISINE
Siége social:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
OPTIMUM 700, Electric cooking top, radiant hobs
P075477
MODEL
B-D706.FR
DIMENSIONS (mm)
Height 297
Width 400
Depth 730
Pyroceramic plate 546 x 334
PACKAGING (mm)
Height 490
Width 500
Depth 830
WEIGHT (KG)
COMPOSITION OF THE TOP
Front hob 3.5 or 4 kW 1
Back hob 1.7 kW 1
ELECTRICITY (Three-phase 230V+T or 400V+N+T)
Power (kW) 230V 3a.c. 5.2
400V 3Na.c. 5.7
Max. Intensity (A) 230V 3a.c. 20
400V 3Na.c. 10
ELECTRIC CONNECTION
Electric outlet at 615 mm above the floor
This document is not contractual; Edition 05/2007 – 3BE0374FT
ELECTRIC connection
(Foresee a cable with 1.5 m free end)
