Bonnet OPTIMUM 700 - Page 5

Page 4 3BE390580NI – 07/07
BONNET CIDELCEM GRANDE CUISINE
Siége social:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
OPTIMUM 700, Electric cooking top, snack plates
P075480 P075481
MODEL
B-D706.SN400 B-D706.SN800
DIMENSIONS (mm)
Height 355 355
Width 400 800
Depth 730 730
Snack plate 550 x 354 550 x 754
Useful surface (dm²) 17 36
PACKAGING (mm)
Height 550 550
Width 500 900
Depth 830 830
WEIGHT (KG)
50 90
COMPOSITION OF THE TOP
Plate width 400 1 -
Plate width 800 - 1
ELECTRICITY (Three-phase 230V+T or 400V+N+T)
Power (kW) 230V 3a.c. 3.9 7.8
400V 3Na.c. 3.9 7.8
Max. intensity (A) 230V 3a.c. 9.8 19.6
400V 3Na.c. 5.7 11.4
ELECTRIC CONNECTION
Electric outlet at 615 mm above the floor
This document is not contractual; Edition 07/2007 – 3BE0375FT
ELECTRIC connection
(Foresee a cable with 1.5 m free length)
