Bonnet OPTIMUM 700 - Page 7

Page 6 3BE390580NI – 07/07
BONNET CIDELCEM GRANDE CUISINE
Siége social:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
OPTIMUM 700, Electric cooking top, bain marie
P075486
MODEL
B-D706.BM400
DIMENSIONS (mm)
Height 297
Width 400
Depth 730
PACKAGING (mm)
Height 490
Width 500
Depth 830
WEIGHT (KG)
COMPOSITION OF THE TOP
Number of GN 1/3 tanks 3
ELECTRICITY (Single-phase or three-phase 230V+T or 400V+N+T)
Power (kW) 230V a.c. 1.5
230V 3a.c. 1.5
400V 3Na.c. 1.5
Max intensity (A) 230V a.c. 6.5
230V 3a.c. 6.5
400V 3Na.c. 6.5
COLD WATER
Pressure 2.5/6 bars
Connection
Hose ∅ 12/17
DRAINAGE
From front
ELECTRIC CONNECTION
Electric outlet at 615 mm above the floor
This document is not contractual; Edition 05/2007 – 3BE0377FT
ELECTRIC connection
(Foresee a cable with 1.5 m free
length)
COLD WATER
