OPTIMUM 700, Electric cooking top, induction wok
P075479
MODEL
B-D706.WI
DIMENSIONS (mm)
Height 297
Width 400
Depth 730
PACKAGING (mm)
Height 490
Width 500
Depth 830
WEIGHT (KG)
ELECTRICITY (Three-phase 400V+T)
Power (kW) 400V 3a.c. 5
Max. intensity (A) 400V 3a.c. 7.3
AIR INLET
Dimension of filter 250 x 250
Environment
Ambient temperature ≤ 32°C
ELECTRIC CONNECTION
Electric outlet at 615 mm above the floor
This document is not contractual; Edition 05/2007 – 3BE0379FT
ELECTRIC connection
(Foresee a cable with 1.5 m free length
