1.4 Product options
The options of the product are marked with an asterisk (*) in the text of this manual. The options
that are actually included on the product manufactured are mentioned on the drawing list of the
enclosed drawing.
1.5 Abbreviations
FL Fail Lock
ACS Access Control System
FS Fail Safe
N.C. Normally Closed
FL/FS Fail Lock Entry Fail Safe Exit
N.O. Normally Open
NE No Exit
MCB Main Control Board
CW Clock-Wise Rotation
• CCW Counter Clock-Wise Rotation
I/O Input/Output
• JP Jumper (Control Board)
1.6 Symbols
Warnings and cautions
WARNING!
Risk of personal injury or loss of life.
CAUTION!
The material may be damaged or the operation of the product affected.
2 Product Safety
2.1 Installation and maintenance Safety
WARNING!
Switch off the power supply of the product before working on the product.
WARNING!
When the power supply cannot be switched off, service and maintenance
activities are to be undertaken only by trained engineers fully aware of potential
danger involved.
WARNING!
Be aware and avoid contact with moving parts.
WARNING!
Check that all safety devices and systems are fully operational after installation
of the product or after maintenance has been carried out.
