3.3 Barrier Assembly Options
The THT 100 can be configured with a variety of Barrier Assembly options. The following
Barriers are commonly available. Barrier Bars may vary in finish and material depending upon
order.
Figure 3-3. (A) Standard Barrier, (B) Optional Barrier with Horizontal Strips and
(C) Optional Barrier Lexan Panels with Barrier Bars
3.4 Ceiling Plate
The Ceiling Plate consists of a flat angled sheet material (in matching finish) which is fixed
between the Top Channel Assembly and the Barrier.
Figure 3-4. Ceiling Plate Exploded View
A -
B – Horizontal Strips
C – Bars W/Lexan Pannels
