Removing the activated carbon filter
1
Fig. 8.6 Opening middle lock
[1] Lock, middle
Open the lock [1] in the middle.
1
Fig. 8.7 Opening outer locks
[1] Outer lock
Open both outer locks [1].
Fold the lid (Fig. 7.5; [2]) down until it engages.
8.6 Replacing the activated charcoal
filter
Two activated charcoal filters are used only when the cook-
top extractor is being operated in recirculated air mode.
The activated charcoal filter binds odorous materials which
arise during cooking.
INFO The activated charcoal filters must be replaced
when the fan level indicator indicates F (filter
service display).
BAKF activated charcoal filters can be pur-
chased from your specialist. You can also
contact BORA on its homepage
http://www.bora.com.
Make sure that the cooktop and cooktop extractor are
switched off (see Chapter 6.1).
Wait until the fan display is 0.
1
3 12
Fig. 8.5 Releasing the activated carbon lter housing lid
[1] Outer locks
[2] Activated carbon filter housing cover
[3] Middle lock
