EN
38
Installation
www.bora.com
INFO Below you will find explanations on how to use
the menu and a description of the most important
menu items.
Dealer and service menu overview
Menu item/Description/Selection area Factory setting
B Extraction system
(exhaust air/recirculation system)
Recirculation
C Power management
D Demo mode Off
Tab. 6.3 Menu overview
Calling up the dealer and service menu
Connect the appliance to the power supply.
1
23
4
Fig. 6.48 Calling up the dealer and service menu
The standard display appears and the fan symbol
pulses for 2 minutes.
Long press on the fan button .
4 input points
are shown.
Keep the fan button pressed and at the same time
press the input points
in the specified order.
Menu item B is displayed.
Menu item B:
Configuration of the extraction system
The extraction system must be configured.
There are two operating modes to choose from:
Operating mode
: Recirculation system (factory
setting)
Operating mode
: Exhaust air system
Fig. 6.49 Display Menu item B: Conguring the extraction
system
Select the corresponding operating mode (tap the
corresponding segment on the slider ).
Confirm and save the setting by moving to the next
menu item (tap the multi-function display/indicator
).
Menu item C:
Power management
The total appliance power can be reduced if the required
electrical power cannot be provided at the installation
site.
INFO The cooking zone power restrictions automatically
implemented by the appliance are determined
according to the total power set.
There are three operating modes to choose from:
Power
management
Connection Maximum power
consumption
Fuse
protection
C3 three-phase 7.6 kW 3 x 16 A
C3 two-phase 7.6 kW 2 x 16 A
C3 one-phase 7.6 kW 1 x 32 A
C2 one-phase 4.4 kW 1 x 20 A
C1 one-phase 3.6 kW 1 x 16 A
Tab. 6.4 Power management
