EN
51
Cleaning and Maintenance
www.bora.com
Removing the Pure air inlet nozzle
1
2
Fig. 8.2 Removing air inlet nozzle PURA, PURU
[1] Air inlet nozzle
[2] Access opening
Prerequisite:
The fan level indicator shows
0
.
Reach into the access opening [2] of the air inlet nozzle
[1] with your finger.
Pull the air inlet nozzle [1] up and out.
Removing the stainless steel grease filter
3
2
1
Fig. 8.3 Removing the stainless steel grease lter
[1] Stainless steel grease filter
[2] Handle
[3] Inlet opening
Take hold of the stainless steel grease filter by the
handle [2].
Pull the stainless steel grease filter [1] up and out of
the suction opening [3].
8.4.2 Cleaning the air inlet nozzle and
stainless steel grease filter
INFO If it is no longer possible to clean the stainless
steel grease filter completely, it must be replaced
– see Accessories chapter).
Manual cleaning
Use a cleaner and degreaser in one.
Rinse the air inlet nozzle and stainless steel grease
filter with hot water.
Use a soft brush to clean the air inlet nozzle and
stainless steel grease filter.
After cleaning, rinse the air inlet nozzle and stainless
steel grease filter well.
8.4 Cleaning the cooktop extractor
The air inlet nozzle and stainless steel grease filter absorb
the greasy particles from cooking vapours.
Make sure that the cooktop and cooktop extractor are
switched off (see the Operation chapter).
Wait until the fan indicator shows
0
.
Clean the cooktop extractor in accordance with the
cleaning cycles.
Clean the surfaces of the extraction system using a
soft, damp cloth, detergent or a mild window cleaning
agent.
Soften dried on dirt using a damp cloth (do not scrape
it off!).
8.4.1 Removing the components
Removing the X Pure air inlet nozzle
1
Fig. 8.1 Removing air inlet nozzle PUXA, PUXU
[1] Air inlet nozzle
Prerequisite:
The fan level indicator shows
0
.
Tilt the air inlet nozzle [1] from its horizontal position.
Remove the air inlet nozzle [1] with your other hand.
