18 en | Introduction
AMC2 Modular
Controller
2018-09 | AMC2-4W_UL | Bosch Access Systems GmbH
Figureî3.4: Overview - Interfaces
13 RS-485 extension module bus
14 External tamper contact
15 Connector for power supply
16 Wiegand interfaces forup to 4 card readers
17 Connectors for eight analog inputs
18 Connectors for eight relay outputs
Notice!
All connectors, with the exception of the Ethernet host
interface, are pluggable screw clamp terminals.
