AMC2 Modular
Controller
UL Requirements | en 51
Bosch Access Systems GmbH 2018-09 | AMC2-4W_UL |
Green or Green/Yellow Tamper Connection
AC Power Connection Ethernet Cat 5 Cable
DC Power to AMC2 FG Points
Caution!
Risk of electrical interference.
Make sure to keep the class 2 conductors and the non-power
limited conductors strictly separate.
- Avoid any crossing of the conductors of the two categories.
- Guide the conductors of the two categories through different
knock-outs of the housing.
For detailed diagram, refer to the drawing contained in the
folder titled “_UL” on the delivered CD.
