60 en | Technical Data
AMC2 Modular
Controller
2018-09 | AMC2-4W_UL | Bosch Access Systems GmbH
Display
64,8 mm x 13,9 mm (2.551 x 0.547 in.)
1 line, 16 characters
Power consumption
AMC: 5VA
Total combined output:
3A @ 10-12 Vdc
2.5A @ 24-30 Vdc
Connectors
Pluggable screw connectors
Protection class
IP30
Environment temperature
0° C to 50°C (32° F to 122°F)
Humidity
Up to 95%, without condensation
Housing material
ABS with OC (UL94V-0)
Dimensions
(W/H/D) 232 x 90 x 63mm (8.9 x 3.5 x 2.5 in)
Weight
approx. 0.53kg (1.2lb)
Notice!
The voltage drop from the power supply to the AMC2-4W
affects the AMC interfaces. The total drop must not exceed 2V!
