8 en | Dimensional Outline AutoDome Easy Mount
F01U064856 | 1.0 | 2007.03 Instruction Manual Bosch Security Systems
4 Dimensional Outline
The following illustrations depict the dimensional outlines for the wall mount and for the pen-
dant pipe mounts.
4.1 Wall Mount Dimensions
4.2 Pendant Pipe Mount Dimensions
