Installation Instructions
Climate 5000 Series Gen 3 Wired Wall Thermostat (02.2022)
| 3
Table of Contents
1 Key
to Symbols and Safety Instructions 4
1.1 Key to Symbols 4
2 Remote Controller Specifi cations 5
3 Thermostat Accessories 6
4 Operation of Buttons 7
5 Indicators on LCD 9
6 Installation 10
6.1 Dimensions 10
6.2 Wiring 11
6.3 Remove Back Cover 13
6.4 Mount Back Plate 14
6.5 Battery Installation 15
6.6 Connect to Indoor Unit 16
6.7 Connection Guide to Indoor Units 19
6.7.1 For Wall Mounted Units 19
6.7.2 For 2x2 (9-18K) and 3x3
(24-48K) Cassette Units 27
6.7.3 For Ducted Units 30
7 Operation Guideline 32
7.1 Set Date and Time 32
7.2 Time Scale Selection 33
7.2 Cooling/Heating/Fan Operation 33
7.3 Change Fan Speed 34
7.4 Follow Me Function (Wall Mounted
Indoor Unit Only) 35
7.5 Child Lock 36
7.6 Key Pad Tone Setting 36
7.7 °F / °C Selection 36
7.8 Turbo Mode
(HEAT/COOL modes only)
36
7.9 Swing Function 37
7.10 Scheduling 38
7.10.1 Programming 7-day
Schedule 38
7.10.2 Starting Saved 7-Day
Schedule 41
7.10.3 Set Day Off (Holiday) 42
7.11 Copy Existing Schedule 43
7.12 Delete Saved Schedule 44
7.13 Set Timer On or Off Function 45
7.14 Set Timer On and Off Function 46
