6 720 220 045
Revised 01-11 Subject to change without prior notice
UNIT SPECIFICATIONS
Table 2: Dimensions
Model
Vertical
Unit
(In)
Horizontal
Unit
(In)
Supply Air
Connection
(In)
Return Air
Connection*
(In)
Replacement
Filter Nominal
Size* (In)
Width Depth Height Width Depth Height Width Height Width Height
CP/BP007 21.50 21.50 32.75 21.50 43.00 17.00 11.75 7.75
H: 18.0
V: 17.5
H: 14.0
V: 14.0
H: 15”x20”x1” (1)
V: 15”x20”x1” (1)
CP/BP009 21.50 21.50 32.75 21.50 43.00 17.00 11.75 7.75
H: 18.0
V: 17.5
H: 14.0
V: 14.0
H: 15”x20”x1” (1)
V: 15”x20”x1” (1)
CP/BP012 21.50 21.50 32.75 22.00 45.00 19.50 11.75 13.75
H: 18.0
V: 17.5
H: 14.0
V: 14.0
H: 18”x20”x1” (1)
V: 20”x20”x1” (1)
CP/BP015 21.50 21.50 39.50 22.00 45.00 19.50 13.75 15.75
H: 18.0
V: 18.0
H: 16.0
V: 18.0
H: 18”x20”x1” (1)
V: 20”x20”x1” (1)
CP/BP018 21.50 21.50 39.50 22.00 45.00 19.50 13.75 15.75
H: 18.0
V: 18.0
H: 16.0
V: 18.0
H: 18”x20”x1” (1)
V: 20”x20”x1” (1)
CP/BP024 21.50 26.25 47.50 26.00 54.50 22.00 13.75 15.75
H: 30.0
V: 22.0
H: 18.5
V: 22.0
H: 16”x20”x1” (2)
V: 24”x24”x1” (1)
CP/BP030 24.25 33.50 47.50 30.00 68.00 22.00 15.75 15.75
H: 34.0
V: 28.0
H: 18.5
V: 22.0
H: 18”x20”x1” (2)
V: 24”x30”x1” (1)
CP/BP036 24.25 33.50 47.50 30.00 68.00 22.00 15.75 15.75
H: 34.0
V: 28.0
H: 18.5
V: 22.0
H: 18”x20”x1” (2)
V: 24”x30”x1” (1)
CP/BP042 26.00 33.50 58.50 30.00 79.00 22.00 17.75 17.75
H: 46.5
V: 28.0
H: 18.5
V: 30.0
H: 24”x20”x1” (2)
V: 16”x30”x1” (2)
CP/BP048 26.00 33.50 58.50 30.00 79.00 22.00 17.75 17.75
H: 46.5
V: 28.0
H: 18.5
V: 30.0
H: 24”x20”x1” (2)
V: 16”x30”x1” (2)
CP/BP060 26.00 33.50 66.50 30.00 89.00 22.00 17.75 17.75
H: 54.0
V: 28.0
H: 18.5
V: 38.0
H: 28”x20”x1” (2)
V: 20”x30”x1” (2)
CP/BP070 26.00 33.50 66.50 30.00 89.00 22.00 17.75 17.75
H: 54.0
V: 28.0
H: 18.5
V: 38.0
H: 28”x20”x1” (2)
V: 20”x30”x1” (2)
* H = Horizontal Unit; V = Vertical Unit
IN-WARRANTY MATERIAL RETURN
When contacting your Representative for service or
replacement parts, refer to the model and serial
number of the unit as stamped on the data plate
attached to the unit.
Material may be returned to the factory only with
permission of an authorized factory representative. A
“Warranty Return Material” tag must be attached to
the returned material. Assure that all of the information
as called for on the tag is lled out completely and
accurately to expedite handling and insure prompt
issuance of credits.
Unit Specications CP/BP Series 15
Freight charges for all items returned to the factory
shall be prepaid. The return of the part does not
constitute an order for a replacement. Therefore, a
purchase order must be entered through your nearest
representative. The order shall include the part
number, model number, and serial number of the unit
involved. If the part is within the warranty period, and
after our inspection of the returned part proves that
the failure is due to faulty material or workmanship a
credit or replacement part will be issued.
Caution
Parts returned without a completed “Warranty
Return Material” tag will not be credited.
