Table 3: Fluid Pressure Drops
Model
Flow Rate
(GPM)
Pressure
Drop (FOH)
Pressure
Drop (PSI)
Model
Flow Rate
(GPM)
Pressure
Drop (FOH)
Pressure
Drop (PSI)
007
1 1.4 0.61
030
4 1.2 0.51
1.5 2.9 1.26 5.5 2.1 0.91
2 4.9 2.11 7 3.2 1.41
3 10.1 4.38 10 6.1 2.67
4 16.9 7.34 13 9.9 4.28
009
1.5 2.3 1.00
036
5 2.3 1.01
2 3.9 1.68 7.5 4.8 2.09
2.5 5.8 2.51 10 8.1 3.51
3.25 9.3 4.03 12.5 12.1 5.25
4 13.5 5.85 15 16.8 7.29
012
2 1.7 0.72
042
7 2.8 1.22
3 3.4 1.50 8.75 4.2 1.82
4 5.8 2.51 10.5 5.8 2.53
5.5 10.2 4.45 13.25 8.9 3.85
7 15.8 6.88 16 12.4 5.41
015
2 1.6 0.69
048
8 3.6 1.55
3 3.3 1.44 10.67 6.0 2.61
4 5.5 2.41 12 7.4 3.22
5.5 9.8 4.28 14 9.8 4.25
7 15.2 6.60 16 12.4 5.41
018
3 4.1 1.80
060
9 3.7 1.60
4 7.0 3.02 12 6.2 2.69
5 10.4 4.52 15 9.2 4.02
6.5 16.7 7.25 17.5 12.2 5.30
8 24.2 10.53 20 15.5 6.74
024
3 2.0 0.87
070
10 2.8 1.24
4.5 4.1 1.80 13.5 4.9 2.12
6 6.9 3.01 17 7.4 3.22
8 11.6 5.06 20.5 10.4 4.50
10 17.4 7.56 24 13.8 5.98
