5.7.9 Connection alternative for EMS bus
Fig. 13 Connection alternative for EMS bus
[A] Star configuration and connection in series with external junction
box
[B] Star configuration
[C] Serial connection
[1] Installation circuit board
[2] Accessory modules (room temperature-dependent controller,
heating circuit module and solar module)
B CA
