32206G Page 10 © 2002 Bosch Security Systems
• Four door states: Locked, Unlocked, Secured, Fire Unlock.
• Disarm states using a token
• Pre-warn for holding door open too long
• Disarm system before or after a door opens
• Automatic Unlock door on disarm, Locked Door when armed
• Optional Deactivate strike when the door opened
• Interlock point assignment to prevent access until interlock point is normal.
• 1000 Cards/Tokens
• Fourteen programmable levels of access authority
• Users can be added or deleted remotely, locally and with Command Center
2.3.2 Displays and Reports
• Access Granted with user ID and User Name
• No Entry with user ID and door User Name
• Request to Enter with door point text
• Request to Exit with door point text
• Door Unlocked with door point text
• Door Locked with door point text
• Alarm Point ### with door point text
• Trouble Point ### with door point text
• Missing Point ### with door point text
• Please Close Door with door point text
2.4 Materials Included
Bosch Security Systems ships the D9210B Access Control Interface module pre-assembled from the factory with a power
supply, in its own can, or as a unit less can. You will receive the following parts with your package depending upon what
model is ordered, (see Section 2.5 Ordered Separately, p.11).
• D136 removable relay mounted on the board.
• Battery Leads (for the D9210BLC).
• 1 kΩ 1/2 watt end of line resistor.
• Literature Pack containing: D9210B Operation and Installation Guide (P/N:32206), D9210 Program Entry
Guide (P/N:32207), ACCESS Program Record Sheet (P/N:32208), and Power Supply Installation
Instructions.
• Hardware pack containing: three #6x3/8 self-tapping sheet metal screws to secure the module on the
mounting skirt or the enclosure. Two strain relief cable ties.
