Bosch DX4010V2 User Manual

DX4010V2 | Installation Instructions | 6.0 Remote Programming Direct Connection
8 Bosch Security Systems, Inc. | 9/08 | F01U083036-01
Table 3: Option Bus Address DIP Switch Settings
Some automation software packages might require that you restart the application if USB
connection is lost during use.
DIP Switch Settings
DIP
Switches
S1 S2 S3 S4 S5 S6 S7 S8
Module
Address
1 2 4 8 16 32
(Mode)
64
(Option/SDI)
128
(Checksum +1)
0* ON ON ON ON ON OFF ON OFF
1 OFF ON ON ON ON OFF ON OFF
2 ON OFF ON ON ON OFF ON OFF
3 OFF OFF ON ON ON OFF ON OFF
4 ON ON OFF ON ON OFF ON OFF
5 OFF ON OFF ON ON OFF ON OFF
6 ON OFF OFF ON ON OFF ON OFF
7 OFF OFF OFF ON ON OFF ON OFF
8 ON ON ON OFF ON OFF ON OFF
9 OFF ON ON OFF ON OFF ON OFF
10 ON OFF ON OFF ON OFF ON OFF
11 OFF OFF ON OFF ON OFF ON OFF
12 ON ON OFF OFF ON OFF ON OFF
13** OFF ON OFF OFF ON OFF ON OFF
14** ON OFF OFF OFF ON OFF ON OFF
15 OFF OFF OFF OFF ON OFF ON OFF
134 ON ON OFF ON ON ON ON ON
135 OFF ON OFF ON ON ON ON ON
136 ON OFF OFF ON ON ON ON ON
137 OFF OFF OFF ON ON ON ON ON
138 ON ON ON OFF ON ON ON ON
139 OFF ON ON OFF ON ON ON ON
140 ON OFF ON OFF ON ON ON ON
141 OFF OFF ON OFF ON ON ON ON
142 ON ON OFF OFF ON ON ON ON
143 OFF ON OFF OFF ON ON ON ON
144 ON OFF OFF OFF ON ON ON ON
145 OFF OFF OFF OFF ON ON ON ON
250 ON ON ON ON ON ON ON ON
251 OFF ON ON ON ON ON ON ON
252 ON OFF ON ON ON ON ON ON
253 OFF OFF ON ON ON ON ON ON
* Installer’s mode: Use for direct connection of remote programming and diagnostic tools.
** DS7412 emulation
The DS7400Xi (USA) only supports one DX4010V2.
Option bus control panels: D6412, D4412, DS7240, DS7220, DS7400Xi (v2.02 or higher).
