DX4010V2 | Installation Instructions | 6.0 Remote Programming Direct Connection
Bosch Security Systems, Inc. | 9/08 | F01U083036-01 9
Table 4: SDI Bus Address DIP Switch Settings
SDI DIP Switch Settings
SDI DIP
Switches
S1 S2 S3 S4 S5 S6 S7 S8
Module
Address
1 2 4 8 16 32
(Mode)
64
(Option/SDI)
128
(Checksum +1)
80* ON ON ON ON OFF OFF OFF OFF
81 OFF ON ON ON OFF OFF OFF OFF
82 ON OFF ON ON OFF OFF OFF OFF
83 OFF OFF ON ON OFF OFF OFF OFF
84 ON ON OFF ON OFF OFF OFF OFF
85 OFF ON OFF ON OFF OFF OFF OFF
86 ON OFF OFF ON OFF OFF OFF OFF
87 OFF OFF OFF ON OFF OFF OFF OFF
88** ON ON ON OFF OFF OFF OFF OFF
89 OFF ON ON OFF OFF OFF OFF OFF
8A ON OFF ON OFF OFF OFF OFF OFF
8B OFF OFF ON OFF OFF OFF OFF OFF
8C ON ON OFF OFF OFF OFF OFF OFF
8D OFF ON OFF OFF OFF OFF OFF OFF
8E ON OFF OFF OFF OFF OFF OFF OFF
8F OFF OFF OFF OFF OFF OFF OFF OFF
Positions 5, 6, and 8 are not used for SDI bus.
* Used for BIS, PC 9000, and other third party applications.
** Used for RPS and alternate communication.
SDI bus control panels (v6.0 or higher): D9412GV2, D7412GV2, D7212GV2, D9412G, D7412G,
D7212G, D9124, D9112, D7412, and D7212.
