Bosch FAP-DO420 - Detector Connection

Y
Ø 100
Y
X
Ø 120
55
147.8
22.7
Connection
i
Notice!
Keep shield wire as short as possible and insulate.
5.3
18 en | Connection
Automatic Fire Detectors LSN
improved
12/2012 | 8.1 | F.01U.003.448 Operation Guide Bosch Sicherheitssysteme GmbH
