Bosch FLEXIDOME starlight - Technical Specifications; Electrical Specifications; Sensor Specifications; Video Stream Specifications

VDA-PMT-DOME –Pendant Pipe Mount
656 (25.82) mm (in)
Ø158 (6.23)
88 (3.47)
88 (3.47)
Ø11 (0.43)
VDA-CMT-DOME –Corner Mount
90°
90 (3.54)
81 (3.21)
mm (in)
25 (0.98)
107 (4.19)
146 (5.75)
180 (7.09)
3-3/4"NPT
Technical specifications
Electrical
Power Supply 24 VAC 50/60 Hz
12 VDC
Power-over-Ethernet 48 VDC nominal
Current Consumption 500 mA | 600 mA IVA (12 VDC)
450 mA | 500 mA IVA (24 VAC)
150 mA | 175 mA IVA (PoE 48 VDC)
Power Consumption 6 W | 7.2 W IVA
PoE IEEE 802.3af (802.3at Type 1)
Sensor
Type 1/3‑inch CMOS HD
Sensor Pixels 1312 x 1069 (1.4MP)
Video streams
Video compression H.264 (ISO/IEC 14496-10); M- JPEG,
JPEG
Streaming Multiple individually configurable
streams in H.264 and M-JPEG,
configurable frame rate and bandwidth.
Regions of Interest (ROI)
Overall IP Delay Min. 120 ms, Max. 240 ms
GOP structure IP, IBP, IBBP
Encoding interval 1 to 60 (50) ips
Resolutions (H x V)
• 720p HD 1280 x 720
• D1 4:3 (cropped) 704 x 480
• SD upright
(cropped)
400 x 720
• 480p SD Encoding: 704 x 480;
Displayed: 854 x 480
• 432p SD 768 x 432
• 288p SD 512 x 288
• 240p SD Encoding: 352 x 240;
Displayed: 432 x 240
• 144p SD 256 x 144
Sensitivity (3200 K, scene reflectivity 89%, 30 IRE)
Lens 3 - 9 mm (F1.2)
• Color 0.017 lx (0.0017 fc)
• Monochrome 0.0057 lx (0.00057 fc)
Lens 10 - 23 mm (F1.6)
• Color 0.03 lx (0.003 fc)
• Monochrome 0.01 lx (0.001 fc)
Day/Night Color, Monochrome, Auto
White Balance ATW (2500 to 10000K), ATW hold and
manual
Indoor and Outdoor ATW
Shutter Automatic Electronic Shutter (AES)
Fixed (1/60 [1/50] to 1/150000)
selectable
Default shutter
Backlight compensation
(IVA)
Off/Auto/IntelligentAE (iAE)
Backlight compensation
(non-IVA)
Off/Auto/BLC
Noise reduction Intelligent Dynamic Noise Reduction
(iDNR) with separate temporal and spatial
adjustments
Contrast enhancement On/off
Sharpness Sharpness enhancement level selectable
5 | FLEXIDOME starlight HD 720p60 VR
