Dynamic Range 84 dB typical
Privacy Masking Four independent areas, fully
programmable
Video Motion Analysis Intelligent Video Analysis
Audio
Standard AAC
G.711, 8kHz sampling rate
L16, 16kHz sampling rate
Signal-to-noise ratio > 50 dB
Audio Streaming Full duplex / half duplex
Input/output
Analog Video out CVBS (PAL/NTSC), 1 Vpp, BNC, 75 Ohm
Analog Video out
(service only)
CVBS (PAL/NTSC), 1 Vpp, 2.5 mm jack,
75 Ohm (non-protected)
Audio 1 x mono line in, 1 x mono line out
• signal line in 12 kOhm typical, 1 Vrms max
• signal line out 1 Vrms at 1.5 kOhm typical,
Alarm 2 inputs
• activation
voltage
+5 VDC to +40 VDC
(+3.3 VDC with DC-coupled 22 kOhm pull-
up resistor)
Relay 1 output
• voltage 30 VAC or +40 VDC
Maximum 0.5 A continuous, 10VA
Local Storage
Internal RAM 10 s pre-alarm recording
Memory card slot Supports SDHC and SDXC microSD cards
Recording Continuous recording, ring recording.
alarm/events/schedule recording
Software Control
Unit Configuration Via web browser or Configuration Manager
Software update Remote programmable
Network
Protocols IPv4, IPv6, UDP, TCP, HTTP, HTTPS,
RTP/RTCP, IGMP V2/V3, ICMP,
ICMPv6, RTSP, FTP, Telnet, ARP,
DHCP, SNTP, SNMP (V1, MIB‑II),
802.1x, DNS, DNSv6, DDNS, SMTP,
iSCSI, UPnP (SSDP), DiffServ (QoS),
LLDP, SOAP, Dropbox, CHAP, Digest
Authentication.
Encryption TLS 1.0, SSL, DES, 3DES, AES
(optional)
Ethernet 10/100 Base-T, auto-sensing, half/full
duplex
Ethernet connector RJ45
Connectivity ONVIF Profile S, Auto-MDIX
Optical
Lens 3 to 9 mm Automatic Varifocal (AVF) SR
lens
- or –
10 to 23 mm Automatic Varifocal (AVF) SR
lens
Adjustment Motorized zoom/focus
Iris control Automatic iris control
Viewing angle (3 to
9 mm)
Wide: 96º x 52º (H x V)
Tele: 32º x 18º (H x V )
Viewing angle (10 to
23 mm)
Wide: 28º x 15º (H x V)
Tele: 12.4º x 6.9º (H x V )
Mechanical
Dimensions (D x H) 158 x 124 mm (6.22 x 4.89 in)
Weight 0.85 kg (1.87 lb)
1.28 kg (2.82 lb) with SMB
Mounting Flush mount or surface mount
Color White (RAL9010) trim ring with black inner
liner
Adjustment range 360º pan, 90º tilt, ±90º twist
Dome bubble Polycarbonate, clear with UV blocking anti-
scratch coating
Trim ring Aluminum
Environmental
Operating temperature -30 ºC to +50 ºC (-22 ºF to +122 ºF)
Cold start temperature -20 ºC (-4 ºF)
Storage temperature -50 ºC to +70 ºC (-58 ºF to +158 ºF)
Operating humidity 5% to 93% relative humidity
Storage humidity Up to 98% relative humidity
Impact protection EN 50102, IK10
Water/dust protection IP 66 and NEMA Type 4X
Environmental
Test Method
EN 50130-5:2011 Alarm systems Part 5
(Class IV Outdoor in general)
Ordering information
FLEXIDOME HD 720p60 VR 3-9 mm
1/3-inch CMOS, IP Vandal-Resistant Dome Camera,
720p60, 3-9 mm SR lens
Order number NIN-733-V03P
6 | FLEXIDOME starlight HD 720p60 VR
