Installation Instructions
Bosch IDS BOVB20 Split System Heat Pump - BTC 761701316 C (02.2022)
14 Start Up
14.1 System Start Up
1. Ensure Sections 7, 8, 9, 10, 11, and 12 have been completed.
2. Set System Thermostat to OFF.
Figure 36
3. Turn on disconnect to apply power to the indoor and outdoor units.
Figure 37
ON
OFF
4. Once power is supplied to the outdoor unit. LEDS on the Gateway will turn on.
Figure 38
A LED sequence may fl ash on gateway for up to 6 minutes if there is a
fi rmware update.
5. Open up the Bosch EasyAir app and "Add a New Unit". The app will prompt you
to scan the outdoor unit Serial Number and Gateway QR code.
Figure 39
6. Upon initial unit installation, wait one (1) hour before starting the unit if
compressor crankcase heater is used and the outdoor ambient temperature is
below 70 ºF.
Figure 40
60 MIN.
7. Set system thermostat to ON.
Figure 41
To Next Page
