18 IDS2.1 Gateway Functionality
Figure 75
1 42
3
7 6
5
1. Power LED
2. Cellular LED
3. Bluetooth LED
4. Fault LED
5. Factory (Diagnostic) Button
6. Connect (Bluetooth) Button
7. Reset Button
The Gateway Assembly includes the Gateway and Antenna, along with
associated wiring harness and clips.
