Bosch IMSA Prototype Classes Scrutineering System - Pitot Tube; Laser Ride Height; Temp Sensor

3 | Components
12 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
3.3.3 Pitot Tube
Functional Description: Temperature and pressure sensor
Use Case:
 Dynamic Conditions:
o Measure dynamic conditions of air flowing over the car.
 Mounting Note:
o Pitot sensor must be mounted in the IMSA homologated position.
No other pitot tubes are permitted on the car.
Part Number: F02U.V0U.264-01
3.3.4 Laser Ride Height
Functional Description: Dynamic ride height measurement
Use Case:
 Ride Height:
o Measure dynamic ride height of car in multiple locations.
o Each manufacturer may select a sensor to be approved by IMSA.
 Mounting Note:
o Ride height sensors must be mounted in the IMSA homologated
position connected to the scrutineering system if run. No other ride
height sensors are permitted on the car.
 Harness Pinout:
Connector
ASL606-05SC
Pin
Description
1
12V+ KL.30
2
GND
3
Signal
4
5
3.3.5 Temp Sensor
Functional Description: Temperature sensor
Use Case:
 Plenum Temperature (NA engines):
 Intercooler Upstream Temperature (Turbo engines):
 Inlet Port Temperature:
 Cockpit Temperature:
Callout: Driver’s left bank will be Sensor #1
Part Number: F02U.V02.356-01
Temperature Range: -55 to 300 °C
Thread: M6 x 1
Installation Torque: 8 Nm
