5 | Technical Data
16/148 DDU 9 Bosch Motorsport
Max. vibration Vibration profile 1 (see Appendix or
www.bosch-motorsport.com)
Electrical Data
Supply voltage 5 to 18 V
Inputs
Analog channels 4 standard, additional 12 optional
Input range 0 to 5 V
Resolution 12 bit
Switchable pull up resistor For all ANA_IN
Wheel speed inputs 4 Hall-effect or DF11, switchable
Outputs
Sensor supply 5 V ± 1 % (250 mA) 2
Sensor supply 10 V ± 1 % (250 mA) 1
Sensor supply U_Bat 250 mA 1
Sensor ground 4
Environment
External switch for page selection, 12 steps B 261 209 658-01
External switch for brightness adjustment or
page selection, 6 steps
B 261 209 659-01
Optional Upgrades
USB_DATA
USB-Port unlocked (Rugged USB flash drive
Bosch File System (BFS) format included,
works with Bosch File System (BFS) pre-
formatted USB Flash drive only)
F 02U V02 214-01
Adapter cable to USB-Port (included in Up-
grade USB_DATA)
F 02U V01 343-01
Adapter for wiring harness (included in Up-
grade USB_DATA)
F 02U 002 996-01
CCP_MASTER
CCP-Master (ASAP2 file from ECU manufac-
turer required)
F 02U V02 213-01
ETHER_TELE
LTE Ethernet Telemetry
F 02U V02 138-01
FULL_LOG_1
Enable full logging performance of 3 GB par-
tition 1
F 02U V02 304-01
FULL_LOG_2
Enable full logging performance of 1 GB par-
tition 2
F 02U V02 305-01
I_O EXTENS
Enable additional 12 analog input channels
F 02U V02 205-01
