Technical Data | 5
Bosch Motorsport DDU 9 15/148
5 Technical Data
The display DDU9 integrates a programmable full color dashboard display with a data
logging system for motorsport applications for a very competitive price. Additional input
devices can be connected via Ethernet and CAN buses.
Data Analysis Software WinDarab is available free of charge as “WinDarab V7 free” on our
website. A basic logging function of 100 channels with recording of 50 ms (3 GB) is always
included. The logger can be upgraded to full logging performance (max. 1 ms). In addition
a 2
nd
logging partition of 1 GB (e.g. for long term recording) can be activated.
Customers can implement own graphics, pictures etc. on the 12 freely configurable dis-
play pages. For quick data transfer from the car e.g. during pit stop, data copy to a USB
stick is available as an option. The stick is connected to the wiring harness for the DDU9.
The device comes with 4 analogue and 4 speed inputs as standard; further 12 analogue
inputs are available as optional upgrade.
Display – 5.7” graphic color display
– 12 user configurable display pages
– 10 multicolor freely configurable (RGB) LEDs
Resolution 640 x 480 pixel
Supported image file formats Bmp, gif, jpg, png, tif
Processor 667 MHz Dual Core
Converters 8 kHz AD converters with digital low pass
filter
Internal power source Li/Ion capacitor
Configurable math channels
User configurable CAN in/out messages
Sampling rate 50 ms (standard),
max. 1 ms (optional)
Online data compression
Logging rate Max. 600 kB/s
Recording channels 100 channels (standard),
up to 1,040 in total (optional)
Logged data download speed Max. 1,000 kB/s
Internal storage capacity 3 GB (standard),
plus 1 GB (optional)
LTE Ethernet telemetry support, GSM telemetry support
RS232 for GPS and telemetry
CCP-Master, data acquisition from ECU that support CAN calibration protocol (optional)
Mechanical Data
Size 151 x 126 x 33.5 mm
Weight 540 g
Protection Classification IP54 to DIN 40050, Section 9, Issue 2008
Operating temperature internal -20 to 85°C
Operating temperature Display -20 to 70°C
