Technical Data | 5
Bosch Motorsport DDU 9 17/148
Connectors and Wires
Motorsport connector on Display AS-216-35 PN
Mating connector
AS-616-35 SN
F 02U 000 466-01
Pin Configuration
Pin Name Comment Status
1 KL_31 Incl.
2 KL_15 Incl.
3 KL_30 Incl.
4 Rev_In_3 Hall or DF11 switchable Incl.
5 Rev_In_1 Hall or DF11 switchable Incl.
6 KL_31 Incl.
7 CAN_2_L CAN speed selectable Incl.
8 Ethernet_2_TXP Incl.
9 Ethernet_2_TXN Incl.
10 Sens_Power_12V over current protected Incl.
11 Rev_In_4 Hall or DF11 switchable Incl.
12 Rev_In_2 Hall or DF11 switchable Incl.
13 Laptrigger_In Incl.
14 CAN_2_H CAN speed selectable Incl.
15 CAN_1_H CAN speed selectable Incl.
16 Ethernet_2_RXP Incl.
17 Sens_Gnd_4 fused Incl.
18 Sens_Power 5V over current protected Incl.
19 ANA_IN_3 3.01 kOhm switchable Incl.
20 ANA_IN_4 3.01 kOhm switchable Incl.
21 Time_Sync connection to Bosch ECU Incl.
22 CAN_1_L CAN speed selectable Incl.
23 Ethernet_screen Incl.
24 Ethernet_2_RXN Incl.
25 Sens_Gnd_3 fused Incl.
26 Sens_Power 5V over current protected Incl.
27 ANA_IN_7 3.01 kOhm switchable Opt.
28 ANA_IN_1 3.01 kOhm switchable Incl.
29 USB_Device_DP to Bosch USB stick Opt.
30 RS232_TX_Telemetry Incl.
31 Ethernet_1_TXP Incl.
32 Sens_Gnd_2 fused Incl.
33 Sens_Power_10V over current protected Incl.
34 ANA_IN_8 3.01 kOhm switchable Opt.
35 ANA_IN_10 3.01 kOhm switchable Opt.
36 USB_Device_Gnd to Bosch USB stick Opt.
