5 | Technical Data
18/148 DDU 9 Bosch Motorsport
Pin Name Comment Status
37 USB_Device_DN to Bosch USB stick Opt.
38 RS232_RX_Telemetry e.g. GSM telemetry Incl.
39 Ethernet_1_TXN Incl.
40 Sens_Gnd_1 fused Incl.
41 ANA_IN_11 3.01 kOhm switchable Opt.
42 ANA_IN_9 3.01 kOhm switchable Opt.
43 RS232_TX_GPS Incl.
44 ANA_IN_16 3.01 kOhm switchable Opt.
45 USB_Device_Power to Bosch USB stick Opt.
46 Ethernet_1_RXP Incl.
47 ANA_IN_12 3.01 kOhm switchable Opt.
48 ANA_IN_6 3.01 kOhm switchable Opt.
49 ANA_IN_2 3.01 kOhm switchable Incl.
50 ANA_IN_13 3.01 kOhm switchable Opt.
51 ANA_IN_15 3.01 kOhm switchable Opt.
52 Ethernet_1_RXN Incl.
53 ANA_IN_5 3.01 kOhm switchable Opt.
54 RS232_RX_GPS for GPS sensor input Incl.
55 ANA_IN_14 3.01 kOhm switchable Opt.
