6 | CAN Specification
Bosch Motorsport IMSA Prototype Class Scrutineering Logger 21 / 47
6.2 Team Received Channels
Channel Name
Short Name
Raster
(ms)
Notes
Low Boost Counter**
LowBoostCtrOuting
20
Low overboost counter
High Overboost
Counter**
HighBoostCtrOuting
20
High overboost counter
Overboost Integral**
integral
20
Live overboost integral value
DDU9 Fault
ddu9fault
20
DDU9 Fault Status
PBX90 Fault
pbxfault
20
PBX90 Fault Status
LT4 Fault*
lt4fault
20
LT4 Fault Status
Beacon
b_*
20
Beacon for s/f, Pit In, Pit Out
Position in Class
position
50
Position of car in class
Track Condition
track_cond
50
Track condition
Rainlight On
rainlight
50
Rainlight activiation status
Lap Number
lapnum
50
Current lap number
Driver ID
driver_id
50
Driver ID from Timing and Scoring
DDU9 Temp
tlogger
1000
DDU9 logger core temperature
Cockpit Temp
tcockpit
1000
Car cockpit temperature
PBX90 Temp
tpbx
1000
PBX90 core temperature
GPS Latitude
gpsLatitude
50
GPS latitude
GPS Longitude
gpsLongitude
50
GPS longitude
GPS Speed
gpsSpeed
50
GPS speed
GPS Altitude
gpsAltitude
50
GPS altitude
GPS Time
gpsTime
50
GPS time
Pressure 1*
p21
200
Driver's left bank plenum/pre-throttle pressure
Pressure 2*
p21_2
200
Driver's right bank plenum/pre-throttle pressure
Pressure 3*
p22
200
Driver's left bank manifold/boost pressure
Pressure 4*
p22_2
200
Driver's right bank manifold/boost pressure
Pressure 5*
prestrictor
200
Driver's left restrictor throat pressure
Pressure 6*
prestrictor2
200
Driver's right restrictor throat pressure
Temperature 1*
tplenum
200
Driver's left plenum/pre-intercooler temperature
Temperature 2*
tplenum2
200
Driver's right plenum/pre-intercooler
temperature
Temperature 3*
tmanifold
200
Driver's left manifold/post-intercooler
temperature
Temperature 4*
tmanifold2
200
Driver's right manifold/post-intercooler
temperature
Pitot Pressure
ppitot
20
Pitot tube pressure
Pitot Temperature
tpitot
20
Pitot tube temperature
Logger Status
logger_status
20
DDU9 logger status
USB Status
usb_status
20
USB stick recording status
Lambda 1*
lambda
20
Driver's left lambda value
Lambda 2*
lambda2
20
Driver's right lambda value
Ride Height Front Left
ride_fl
20
Front left dynamic ride height
Ride Height Front
Right
ride_fr
20
Front right dynamic ride height
Ride Height Rear
ride_r
20
Rear dynamic ride height
Volumetric Flow Rate
q_fuelflow
20
Instantaneous volumetric fuel flow rate
Total Volume
V_fuelflow
20
Total volumetric fuel flow
Mass Flow Rate
dm_fuelflow
20
Instantaneous fuel mass flow rate
Total Mass
m_fuelflow
20
Total mass fuel flow
Fuel Temperature
Tfuel
200
Fuel flow meter reported fuel temperature
Flow meter service
time
FFM_Minutes
200
Number of minutes since flow meter calibration
