9 | Starting up
34/148 DDU 9 Bosch Motorsport
6. Disconnect the DDU 9 network cable.
7. Click on the ‘Read Data from Logging Device’ icon.
8. Choose your logger and click ‘OK’ when done.
Click
'read data from
logging device'
The ‘Data Logger Import’ dialog opens.
NOTICE
Refer to the WinDarab V7 manual for instructions on how to use the
‘Data Logger Import’ dialog and for more detailed descriptions and
instructions.
9. Choose the device and the IP address for the device.
10. Click ‘Apply changes’ when done.
Choose your DDU
from dropdown list
11. Connect the DDU 9 network cable.
12. Click on the ‘Current Import’ tab.
13. Click on ‘Import’ in the lower right corner.
If the ‘Import all on connect’ box is checked, the data transmission from the DDU 9
starts automatically. Measurement files are stored automatically in the folder defined
under ‘Settings’.
