Bosch KM3211WH - Page 40

40
ExternaloutfittingExternaloutfitting
ExternaloutfittingExternaloutfitting
Externaloutfitting
KM3211WHKM3211WH
KM3211WHKM3211WH
KM3211WH
．．
．．
．
KM3211WHQKM3211WHQ
KM3211WHQKM3211WHQ
KM3211WHQ
Part Nos. Part Names Order Nos. Q'ty／unit Note
001 KM3211WH BOS Front set-AS SKA7035 1 For KM3211WH
KM3211WHQ BOS Front set-AS SKA7036 1 For KM3211WHQ
002 Front packing S AAP AAPL015 2
003 Front packing L AAP AAPL017 2
004 Lamp seal plate DEC DECK008 1
006 Case top packing EDM EDML001 1
007 Case top cover 2 EDL EDLA005 1
008 Case top cover EDM EDMA003 1
009 Exhaust sylinder packing EDL EDLL002 1
010 Exhause box EDM EDMF001 1 009, 012 also replace
012 Exhause joint packing DHN DHNL003 1
016 Pump fixing plate DHN DHNA007 1 For KM3211WHQ
022 Caution label BOSCH EJX EJXK004 1
023 Plug insulation sheet CRU CRUK002 1
025 Case H EJX EJXA011 1 For KM3211WH 022 also replace
Case QH EJX EJXA001 1 For KM3211WHQ 022 also replace
026 Air themistor 300 BWC BWCH003 1 For KM3211WHQ
027 Cord Bush C1 7355009 1
038 Shield plate EAD EADA011 1 For KM3211WHQ
039 Connection diagram label BOSCH EJX EJXK007 1
040 Raintight seal plate BUB BUBK004 1
050 Connection Cord 2 DMB DMBJ010 1
070 Cross recessed round-head collar N-tapping screw 4X8 SUS410
071 Cross recessed truss type3 EVERTIGHT tapping screw with PW 4X12 SUS410 dacrotized
072 Cross recessed round-head collar N-tapping screw 4X10 SUS410
073 Cross recessed round-head collar N-tapping screw 4X12 SUS410
074
Cross recessed truss type3 S TIGHT tapping screw4X10
SUS410 pre-coating
