General Parts
Indoor or Outdoor Wall Mounted, Power Vented Model
* The above illustration shows an example of installation.
The exact installation configuration may be slightly different.
Main Unit
Flue Collar
Front Cover
Air Inlet
Water Supply Valve
Gas Supply Valve
Water Drain Valve (with Water Filter)
(Inside Water Inlet) ( P32)
Burner On Indicator
Lit during combustion.
Blinks to indicate a problem.
( P36)
(Eg.: KM3211WH)
KM3211WH, KM3211WHQ
* KM3211WH shown, pipe arrangement differs slightly on the KM3211WHQ model.
