Bosch KM3211WH - Page 49

To Next Page

To Previous Page

ElectriccontrollerElectriccontroller

Electriccontroller

KM3211WHKM3211WH

KM3211WH

．．

．

KM3211WHQKM3211WHQ

KM3211WHQ

Part Nos. Part Names Order Nos. Q'ty／unit

Note

700 Relay case EJX SET-AS SHA7706 1

701 Harness H BOSCH EJX EJXJ031 1 For KM3211WH

Harness QH BOSCH EJX EJXJ011 1 For KM3211WHQ

703 Lamp cable conduit CRP CRPJ014 1

705 Relay case cover DEK DEKA014 1

710 Mounting plate for terminal block DZT DZTA006 1

711 Short circuit safety device 240 EJS EJSJ022 1

713 Power cord EJX EJXJ017 1

714 Nylon clamp HP-4N (NK-4N) 7287909 1

715 Nylon clamp HP-5N (NK-5N) 7224001 1

717 Conduit 90-2 CCP CCPJ028 1

721 Cross recessed bind machine screw M3.5X6 SUS430

722 Cross recessed round-head N-tapping screw 4X12 SUS410

730 Transformer EJX EJXJ021 1

731 Transformer cover EJS EJSA021 1

732 Connection Cord 1 DEM DEMJ009 1

733 Conduit R92-250 EJS EJSJ016 1

734 Mounting plate for Transformer for Q EJS EJSA016 1 For KM3211WHQ

735 System select connector EJS EJSJ015 1 For KM3211WHQ

736 Heating level change connector for 83 DTJ DTJJ031 1
