48 | Corner Weights (HZ) LV Heat Pump Series
LV Heat Pump Series8 733 944 336 (2016/09) Subject to change without prior notice
CORNER WEIGHTS (HZ)
WATER COIL VOLUME
Configuration Left Hand Return Right Hand Return
Model Total Left Front*Right Front* Left Back Right Back Left Front*Right Front* Left Back Right Back
LV007-HZ
Lbs9828 21252421 282425
kg 45 13 10 11 11 10 13 11 11
LV009-HZ
Lbs 103 29 23 26 25 23 29 25 26
kg 47 13 10 12 11 10 13 11 12
LV012-HZ
Lbs 105 29 24 26 26 24 29 26 26
kg 48 13 11 12 12 11 13 12 12
LV015-HZ
Lbs 127 36 28 34 29 28 36 29 34
kg 58 16 13 15 13 13 16 13 15
LV018-HZ
Lbs 177 57 36 48 37 36 57 37 48
kg 80 26 16 22 17 16 26 17 22
LV024-HZ
Lbs 181 58 37 48 38 37 58 38 48
kg 82 26 17 22 17 17 26 17 22
LV030-HZ
Lbs 194 61 41 52 41 41 61 41 52
kg 88 28 18 23 19 18 28 19 23
LV036-HZ
Lbs 237 71 49 66 52 49 71 52 66
kg 108 32 22 30 24 22 32 24 30
LV042-HZ
Lbs 231 70 47 64 50 47 70 50 64
kg 105 32 21 29 23 21 32 23 29
LV048-HZ
Lbs 268 87 60 62 60 60 87 60 62
kg 122 39 27 28 27 27 39 27 28
LV060-HZ
Lbs 288 88 65 69 66 65 88 66 69
kg 131 40 29 31 30 29 40 30 31
LV070-HZ
Lbs 316 98 72 76 70 72 98 70 76
kg 143 44 32 35 32 32 44 32 35
*Front is control box end
LV Model Coaxial Coil Volume (gal)
007 0.04
009 0.06
012 0.08
015 0.09
018 0.14
024 0.14
030 0.24
036 0.27
041 0.27
042 0.27
048 0.49
060 0.62
070 0.62
