MAP 5000 Installation | en 25
Bosch Sicherheitssysteme GmbH Installation manual 2018.08 | 23 | F.01U.168.332
Aligning the accessory mounting plate
4 Ensure that the locking clips snap into the bottom mounting rail as shown in the figure
below.
Installing the accessory mounting plate
Refer to Accessory mounting plate overview, page 26 for the locations of the modules that
mount on the accessory mounting plate.
