74 en | Appendices MAP 5000
2018.08 | 23 | F.01U.168.332 Installation manual Bosch Sicherheitssysteme GmbH
8.2 Requirements in accordance with EN 50131 grade 3
Notice!
If not all requirements in accordance with this standard can be satisfied or only a lower grade
can be met, the compliance mark (EN 50131 grade 3) must be either removed or adapted.
8.2.1 Selecting the default setting
1. Select EN50131 grade 3 as the default property values setting (refer to Standard-
compliant programming, page 58).
2. If the panel validation in accordance with EN 50131 grade 3 fails, do not proceed with
programming the panel.
8.2.2 Connectable peripherals
To comply with the requirements for proper functioning of the panel (i.e. detection and
forwarding of intrusion, hold-up, tamper and trouble states), only peripherals may be
connected that are certified in accordance with EN 50131 grade 3 or grade 4.
8.2.3 Arming / disarming without entry / exit delay
Arming outside the secured area, e.g. with arming device
1. Include a new area if not yet present.
2. Connect a free input with the device key switch.
3. Using the wizard, select the type Static or Dynamic, the user and function of the key
switch Arm / Disarm Area. Now select the area that is to be armed / disarmed. For exit
delay, select No Delay.
4. Select the area in the properties field of the Key Switch > Area.
5. In the properties field of the Control Center, include the area in the scope Local Area or
Additional Areas in Scope
Programming two outputs for signaling the armed / disarmed state
1. Connect one free output in each case with the device LED.
2. Using the wizard, program one output with the behavior item Area Armed and a second
output with the behavior item Area Disarmed.
3. The signal must be time-limited. Enter a corresponding time (typically 10 sec. / maximum
30 seconds) for Activation Duration.
Securing access route against unauthorized entry in armed state, e.g. by installing a
blocking element
1. Connect a free output with the device LED.
2. Variant A: Blocking element is actively controlled CLOSED. Using the wizard, program an
output with the behavior item Area Armed
or
Variant B: Blocking element is actively controlled OPEN. Using the wizard, program an
output with the behavior item Area Disarmed.
3. The signal must be static; enter 00:00:00 for Activation Duration.
4. Refer to the manufacturer's connection instructions for further information.
8.2.4 Arming / disarming with entry / exit delay
Arming inside the secured area, e.g. with control center
1. Include a new area if not yet present.
