Bosch Motion Detector User Manual

20 21
5.2 Starting the app and scanning the QR code 5.3 Inserting the battery compartment
Now start the Bosch Smart Home App
and select “Add device”.
Insert the battery compartment from
above into the Motion Detector’s
housing. The LED will start to flash
orange.
The app will prompt you to scan the
QR code on the product. You will
find the QR code on the back of the
housing (see p.15).
From this point, the app guides you
through the installation process. You
will find a detailed description in this
instruction manual.
A battery is included in the scope of delivery.
In order to double the service life, you can also
insert a second battery into the battery com-
partment. To do so, remove the placeholder
from the battery compartment.

Bosch Motion Detector Specifications

General

Technology	Passive Infrared (PIR)
Tamper Protection	Yes
Detection Range	12 meters
Wireless Communication	RF
Operating Temperature	-10°C to +55°C (14°F to 131°F)
Power Source	Battery or wired
