5.0 INSTALLATION AND SETUP
Before you start
Ensure that you have a Bosch Smart Home Controller and the Bosch
Smart Home App, and that you have set both of them up successfully.
You can also use the explanatory video on our website to help
you install your Bosch Smart Home Motion Detector more easily:
www.bosch-smarthome.com/installation
5.1 Separating the housing and fixing bracket
Separate the Motion Detector’s
housing from the mounting bracket.
To do so, use a screwdriver to twist
the turn lock on the underside of the
Motion Detector counterclockwise by
180°, and simultaneously pull away the
housing from the mounting bracket.

Bosch Motion Detector Specifications

General

Technology	Passive Infrared (PIR)
Tamper Protection	Yes
Detection Range	12 meters
Wireless Communication	RF
Operating Temperature	-10°C to +55°C (14°F to 131°F)
Power Source	Battery or wired
