Bosch Motion Detector User Manual

16 17
Item Part Explanation
1 Pre-punched holes For wall mounting
2 Pre-punched holes For corner mounting
3 Bubble level Aid for alignment
4 Theft protection
Remains on wall
in case of theft and sends
signal
5 Turn lock
For separating the housing
and mounting bracket
Motion Detector – front side of mounting bracket
Item Part Explanation
1 Battery
One inserted
123A battery
2
Battery compartment
with placeholder
Option for another
battery
Motion Detector – battery compartment
2
1
2
4
5
3
1
Optional

Bosch Motion Detector Specifications

General

Technology	Passive Infrared (PIR)
Tamper Protection	Yes
Detection Range	12 meters
Wireless Communication	RF
Operating Temperature	-10°C to +55°C (14°F to 131°F)
Power Source	Battery or wired
