Bosch MW1-RX - Belt-pack Transmitter System Overview

Bosch Security Systems | 2006-01 | 9922 141 50701ml
UHF Wireless Microphone System | Installation and User Instructions | en | 12
3.4 Belt-pack transmitter
1 Microphone input socket
2 Power ON/OFF switch
3 Antenna
4 LCD
5 Slider release button to move the slider up and down
6 SET button to activate the menu and to store
selections in the menu
7 UP button (for frequency/lock)
8 DOWN button (for frequency/lock selection)
9 Sensitivity rotary control
10 Belt clip
11 Battery compartment
12 Screw driver to adjust sensitivity
figure 3.7: Belt-pack transmitter
7
8
5
9
10
11
3
1
12
4
6
2
