Bosch Security Systems | 2006-01 | 9922 141 50701ml
UHF Wireless Microphone System | Installation and User Instructions | en | 9
2.3 Handheld microphone
Model no. MW1-HTX-F1
MW1-HTX-F2
Frequency range Model F1:
790 MHz~814 MHz
Model F2:
852 MHz-876 MHz
Channels 193 channels in steps of
125 kHz
Modulation FM frequency modulation
Frequency selection PLL synthesized control
RF output 10 mW
Stability ±0.005%
Frequency deviation ±48 kHz
Spurious rejection >60 dBc
Dynamic range >110 dB
Audio frequency
response
50 Hz~15 kHz
S/N ratio >102 dB
LCD display Frequency, AF level,
battery level
Controls Power ON/OFF,
frequency UP/DOWN
Antenna Integrated
Battery 2 x LR6/AA/UM3 1.5 V
Battery life time Approximately 15 hrs on
alkaline batteries
Weight (excl batteries) 350 g
