44 en | Technical Data FLEXIDOME HD VR
AM18-Q0637 | v1.0 | 2012.12 Installation Manual Bosch Security Systems
Sharpness Sharpness enhancement level selectable
Privacy Masking Four independent areas, fully programmable
Video Analysis Motion+, IVA versions
Lens type 3 to 9 mm or 10 to 23 mm varifocal SR (Super
Resolution)
Auto Varifocal (AVF) adjustment
Automatic iris control
Controls Via web browser or Configuration Manager
User modes 6 pre-defined customizable user modes
LAN interface STP, Ethernet 10/100 Base-T, auto-sensing,
half/full duplex, RJ45
Video encoding
protocols
H.264 (ISO/IEC 14496-10), M-JPEG
Stream (max.) 720p60
Group of pictures IP, IBP, IBBP
Network protocols IPv4, IPv6, UDP, TCP, HTTP, HTTPS, RTP, IGMPV2/
V3, ICMP, RTSP, FTP, Telnet, ARP, DHCP,
SNTP,SNMP (V1, MIB-II), 802.1x, SMTP, iSCSI,
UPnP (SSDP)
Encryption TLS 1.0, SSL, AES (optional)
Analog video BNC connector, CVBS (PAL/NTSC), 1 Vpp, 75 Ohm
Analog video (service
only)
2.5 mm jack, CVBS (PAL/NTSC), 1 Vpp, 75 Ohm,
non-protected
Alarm input Non-isolated closing contact
TTL logic, +5V nominal, +40 VDC max,
(DC coupled with 22 kOhm pull-up to +3.3 VDC)
Relay output Maximum voltage 30 VAC or +40 VDC
Maximum 0.5 A continuous, 10 VA
Audio input 1 Vrms, impedance 12 kOhm
Audio output 1 Vrms, impedance 1.5 kOhm
