R5CON
6--3
1070 072 196-101 (00.06) GB
6.2.2 Output Parameters
P2
Parameter Attribute Description
P2 W Job number
Into this parameter, R5CON writes the number of that job whose status and
error codes are available in the P3 and P4 output parameters.
If an explicit job number has been specified in P1, it will be mirrored in P2.
If after the parameterization with P1 = 16#FFFF no job is finished, the value
16#FFFF will be returned to P2 as a job number.
If after the parameterization of P1 = 16#FFFE no faulty job, but one or more
jobs without error message are finished, the value 16#FFFE will be returned
to P2.
P3
Parameter Attribute Description
P3 W Status / PLC reaction
In this word, the current job status is output with each execution of R5CON.
The current job status is indicated in the high byte of this word.
The low byte of P3 provides a code that recommends to the user a suitable
measure in case of an error (PLC reaction). This code becomes valid after
the job has been finished.
High Byte Low Byte
Code
[hex]
Job Status Code
[hex]
PLC Reaction
00 Job is finished (terminated) without error 00 Error-free operation
01 Job on the RSS is being processed 01 Repeat call of the R5CON function module
02 Job is in the queue of the RSS 02 Change PLC program
03 Job is finished with error 03 Check and change job parameter
04 No job with this job number is being processed 04 Execute R5INIT function module again
05 Execute R5REQ function module again
06 Execute R5CON function module again
50 Undefined error code, no reaction possible
