6.3 Troubleshooting
Situation Action
Status indicator is not green
after the Level 2 Charging
Station is powered on
1. MakesuretheACpowerinputisconnectedcorrectly.
2. TurnOFFtheLevel2ChargingStationandthenbackONusingthe
ON/OFFswitch.
3. If the problem persists, contact Technical Support.
Status indicator does not
ashgreenwhentheLevel2
Charging Station is connected
to the EV
1. Unplugthechargingplugandreconnectitfullytothereceptacleon
the EV.
2. Inspect the cable and plug for damage.
3. Inspect the EV and its receptacle for damage
4. Try to charge with the portable cord set that came with the vehicle;
contact Technical Support.
Statusindicatorashesred
while charging
1. There is a temporary error.
2. WaituntilthetemporaryerrorisresolvedandtheLevel2Charging
Station returns to normal condition. It usually takes less than 10
seconds.
3. If the status indicator doesn’t return to green, turn OFF the Level 2
ChargingStationandthenbackONusingtheON/OFFswitch.
4. If the situation persists, contact Technical Support.
Status indicator is solid red
1. There is a critical error.
2. UnplugthechargingplugfromtheEVimmediately.
3. TurnOFFtheLevel2ChargingStationandthenbackONusingthe
ON/OFFswitch.
4. If the situation persists, contact Technical Support.
