Installation and Operating Instructions
|
Power Max Level 2 Charging Station | 5
|
en
4 Installation
4.1 Important SAFETY WARNINGS and Instructions
IMPORTANT SAFETY INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
WARNING
Danger of electrical shock or injury. Turn OFF power at the panelboard or load center before working
inside the equipment or removing any component. Do not remove circuit protective devices or any
other component until the power is turned OFF.
ThePowerMaxLevel2ChargingStationshouldbeinstalledonlybyalicensedcontractor,and/oralicensed
electrician or trained installation expert in accordance with all applicable state, local and national electrical codes
and standards.
BeforeinstallingthePowerMaxLevel2ChargingStation,reviewthismanualcarefullyandconsultwithalicensed
contractor, licensed electrician, or trained installation expert to ensure compliance with local building practices,
climate conditions, safety standards, and state and local codes.
4.2 Grounding Instructions
This product must be connected to a grounded, metal, permanent wiring system; or an equipment grounding con-
ductor must be run with the circuit conductors and connected to the equipment grounding terminal or lead on the
product.
4.3 Recommended Tools
ThefollowingtoolsarerecommendedforthePowerMaxLevel2ChargingStationinstallation:
} Supplied accessories and components:
– Level 2 Charging Station mounting bracket
– Three (3) Torx T30 screws for securing the Level 2 Charging Station to the mounting bracket
} Installer-supplied components:
– Conduit of appropriate trade size for power wire
– Two (2) screws for securing the main body mounting bracket to the wall
} Recommended tools:
– Torx T30 screwdriver
